Checking a uniformity trial

Source: vignettes/check_trial.Rmd
check_trial.Rmd

Why check first

Every method in the package turns a uniformity trial into a recommended plot size, and every one of them assumes the trial is worth sizing plots against. A grid with missing cells, a harvest outlier, a fertility gradient down one side, or – most importantly – no spatial structure at all, will still produce a number. check_trial() is the step that looks at the raw grid of basic experimental units (BEU) before any model is fitted, so the number you get later is one you can trust.

It reports four things: whether the grid is structurally usable, whether the values are sane, whether there is a trend across the field, and how much spatial structure the field actually has. All of it is computed from the standard geostatistical definitions, so the package depends only on ggplot2.

Data

The example is the simulated uniformity trial shipped with the package (?uniformity_trial): three trials, each an 8 × 12 grid of 1 m² basic units holding a biomass-like measurement.

grid1 <- as.matrix(uniformity_trial[uniformity_trial$trial == "T1",
                                    grep("^col", names(uniformity_trial))])
dim(grid1)
#> [1]  8 12

The matrix must preserve the field layout: rows and columns are not interchangeable, because trend and autocorrelation are directional.

Running the check

chk <- check_trial(grid1)
#> Checking 1 trial(s).
chk
#> Uniformity trial check -- Trial 1
#>   Grid:      8 x 12 = 96 basic units, 0 missing
#>   Shapes:    23 rectangular plot shapes available
#>   Values:    mean 251.013, sd 58.922, CV 23.47%, range [114.590, 368.440]
#>   Outliers:  0 by the boxplot rule
#>   Trend:     rows p = 0.387, columns p = 0.0336
#>   Moran's I: 0.057 (p = 0.367)   rho row 0.059, col 0.104
#>   Variogram: gaussian | nugget 3223.678, sill 3715.746, range 9.54
#>              nugget/sill 0.87 -> weak spatial dependence
#>              little spatial structure: plot size will buy little
#>              precision here, whatever method is used
#>   Issues:    none

The printout is the whole diagnostic at a glance. Reading it top to bottom:

  • Grid / Shapes – the dimensions and how many rectangular plot shapes the grid admits. This matters because the CV-based methods need several shapes to fit a curve; a grid whose sides are prime yields almost none. The count is flagged when it drops below six.
  • Values / Outliers – mean, sd, CV, range, and outliers by the boxplot rule. In a uniformity trial an outlying unit is usually a harvest failure or a typing error, and because it enters every plot shape that contains it, it is worth resolving before anything else.
  • Trend – the p-value of a monotone trend along the rows and along the columns. A gradient in one direction is field fertility, and it is exactly why shapes of equal area but different orientation give different CVs.
  • Moran’s I / rho – global spatial autocorrelation and the first-order autocorrelations that [calc_paranaiba()] uses.
  • Variogram – the fitted model, discussed next.

Reading the variogram

The fitted variogram gives three numbers that bear directly on plot size, and they are the reason the check is more than a data audit.

chk$checks[[1]]$variogram[c("model", "nugget", "sill", "range",
                            "nugget_ratio", "dependence")]
#> $model
#> [1] "gaussian"
#>
#> $nugget
#> [1] 3223.678
#>
#> $sill
#> [1] 3715.746
#>
#> $range
#> [1] 9.543577
#>
#> $nugget_ratio
#> [1] 0.8675723
#>
#> $dependence
#> [1] "weak"

The range is the distance beyond which basic units stop being correlated. A plot larger than the range is averaging units that are already independent – which is the spatial reading of the plateau that fit_lrp() and fit_qrp() estimate empirically from the CV curve. Seeing the range here, before fitting, tells you roughly where that plateau should land.

The nugget-to-sill ratio is the share of variance with no spatial structure. Following Cambardella et al. (1994) it is read as strong dependence (below 0.25), moderate (0.25 to 0.75) or weak (above 0.75). When it is weak, the field varies almost at random from unit to unit, and no choice of plot size will buy much precision – worth knowing before fitting five models to a CV table.

The model is fitted without a spatial-statistics dependency: the range is profiled over a grid and, at each candidate, the nugget and partial sill are solved exactly under non-negativity. Spherical, exponential and Gaussian shapes are all tried and the best weighted fit is kept.

The field map

The plot() method draws the trial as a map: an ordinary-kriging surface built from that variogram, with the basic units drawn on top and filled on the same colour scale. The surface shows where the field is systematically better or worse; the points show the data the surface came from, so an interpolation artefact cannot be mistaken for a measurement.

plot(chk)

The default palette is viridis, which is perceptually uniform and readable in greyscale and to colour-blind readers. "blues" gives the classic look, and point_values = FALSE draws the units as plain position markers instead of filling them:

plot(chk, palette = "blues", point_values = FALSE)

When the variogram shows weak spatial dependence the surface is mostly telling you about the interpolation rather than the field, and surface = FALSE gives the honest picture – the data alone:

plot(chk, surface = FALSE)

Saving works as elsewhere in the package:

plot(chk, save = TRUE, file = "trial.tiff", format = "tiff", dpi = 300)

Several trials at once

Given a named list of grids, the check runs on each and the summary is one row per trial:

grids <- lapply(split(uniformity_trial, uniformity_trial$trial),
                function(d) as.matrix(d[, grep("^col", names(d))]))

check_trial(grids)$summary
#> Checking 3 trial(s).
#>   trial rows cols n_missing n_shapes     mean       cv n_outliers   morans_i
#> 1    T1    8   12         0       23 251.0129 23.47375          0 0.05689653
#> 2    T2    8   12         0       23 256.1666 22.58366          4 0.10942413
#> 3    T3    8   12         0       23 244.5397 24.61861          1 0.08041496
#>      range nugget_ratio dependence n_issues
#> 1 9.543577   0.86757225       weak        0
#> 2 1.429325   0.02860592     strong        0
#> 3 1.386393   0.57994864   moderate        0

The maps are then faceted and share one colour scale, which is what makes them directly comparable:

plot(check_trial(grids))
#> Checking 3 trial(s).

When the grid is awkward

A grid whose sides are prime admits almost no plot shapes, and the check says so rather than letting the CV-based methods fail later:

check_trial(matrix(rnorm(77, 100, 10), nrow = 7))$checks[[1]]$issues
#> Checking 1 trial(s).
#> [1] "only 3 plot shape(s) available from a 7 x 11 grid"

Fitting the variogram is the only appreciable computation. With a very large grid, or when you only want the structural and value checks, variogram = FALSE skips it.

Where this fits

check_trial() is the entry point of the workflow. Once a trial passes, build the CV table with vignette("cv_shapes"), fit the models with vignette("lrp"), vignette("qrp") and vignette("mcm"), or use the raw grid directly with vignette("paranaiba"). To see every method’s recommendation side by side, see vignette("compare").

References

Cambardella, C. A. et al. (1994). Field-scale variability of soil properties in central Iowa soils. Soil Science Society of America Journal, 58(5), 1501-1511.

Matheron, G. (1963). Principles of geostatistics. Economic Geology, 58(8), 1246-1266.

Webster, R. & Oliver, M. A. (2007). Geostatistics for Environmental Scientists, 2nd ed. Wiley, Chichester.
